型號名稱 |
能力M3/ MIN(SCFM) |
長X寬X高MM(IN) |
重量KG(LB) |
連接空氣進/出 |
HC-7 |
1,088 (677) |
1,473(58)x 2,032(80)x2,515(99) |
2,109 (4,650) |
2"FLG |
HC-9 |
1,344 (836) |
1,549(61)×2,438(96)×2,540(100) |
2,336 (5,150) |
3"FLG |
HC-14 |
1,936 (1,204) |
1,778(70)x2,279(109)x2,565(101) |
2,721 (6,000) |
3"FLG |
HC-21 |
3,023 (1,880) |
1,981(78)x2,819(111)x2,667(105) |
4,490 (9,900) |
4"FLG |
HC-30 |
4,354 (2,708) |
2,642(104)×3,200(126)×2,769(109) |
4,569 (10,075) |
4"FLG |
HC-41 |
5,926 (3,500) |
2,743(108)x3,327(131)x2,845(112) |
5,533 (12,200) |
6"FLG |
HC-54 |
7,740 (4,814) |
2,845(112)x3,556(140)x2,921(115) |
7,846 (17,330) |
6"FLG |
HC-69 |
9,796 (6,093) |
2,997(118)×4,420(174)×2,997(118) |
9,195 (20,275) |
6"FLG |
HC-85 |
12,093 (7,522) |
3,759(148)×4,978(196)×3,226(127) |
10,567 (23,300) |
8"FLG |
HC-103 |
14,632 (9,101) |
3,962(156)×4,902(193)×3,302(130) |
13,379 (29,500) |
8"FLG |
HC-122 |
17,415 (10,832) |
4,064(160)×5,461(215)×3,404(134) |
15,102 (33,300) |
8"FLG |
HC-143 |
20,438 (12,712) |
4,216(166)×5,537(218)×3,404(134) |
16,916 (37,300) |
8"FLG |
HC-166 |
23,703 (14,743) |
4,369(172)×6,147(242)×3,556(140) |
19,410 (42,800) |
10"FLG |
