型號名稱 |
能力M3/ MIN(SCFM) |
加熱器功率 |
長X寬X高MM(IN) |
重量KG(LB) |
連接空氣進/出 |
EH150 |
4.2 (150) |
2 |
813(32.0)×1,130(44.5)×1,676(66.0) |
344 (758) |
1"不擴散條約" |
EH200 |
5.7 (200) |
3 |
813(32.0)×1,232(48.5)×1,702(67.0) |
414 (913) |
1 1/2"NPT |
EH250 |
7.1 (250) |
3 |
889(35.0)×1,334(52.5)×1,727(68.0) |
508 (1,119) |
1 1/2"NPT |
EH300 |
8.5 (300) |
3 |
889(35.0)×1,334(52.5)×1,727(68.0) |
540 (1,191) |
1 1/2"NPT |
EH400 |
11.3 (400) |
4.5 |
864(34.0)×1435(56.5)×2,083(82.0) |
698 (1,539) |
2"不擴散條約" |
EH500 |
14.2 (500) |
4.5 |
864(34.0)×1435(56.5)×2,083(82.0) |
774 (1,707) |
2"不擴散條約" |
EH600 |
17.0 (600) |
6 |
1,194(47.0)x1,626(64.0)x2,184(86.0) |
1,075 (2,369) |
3"不擴散條約" |
EH800 |
22.7 (800) |
9 |
1,194(47.0)x1,626(64.0)x2,184(86.0) |
1,216 (2,681) |
3"不擴散條約" |
EH1000 |
28.3 (1,000) |
9 |
1,219(48.0)x1,994(78.5)x2,032(80.0) |
1,380 (3,043) |
3"不擴散條約" |
EH1200 |
34.0 (1,200) |
12 |
1,219(48.0)x1,994(78.5)x2,032(80.0) |
1,490 (3,285) |
3"不擴散條約" |
EH1500 |
42.5 (1,500) |
15 |
1,397(55.0)×2,134(84.0)×2,337(92.0) |
2,032 (4,480) |
3"不擴散條約" |
EH1800 |
51.0 (1,800) |
18 |
1,524(60.0)×2,134(84.0)×2,337(92.0) |
2,248 (4,956) |
4 FLG |
EH2100 |
59.5 (2,100) |
18 |
1,524(60.0)×2,134(84.0)×2,337(92.0) |
2,427 (5,350) |
4 FLG |
EH3000 |
84.9 (3,000) |
30 |
1,854(73.0)×2,438(96.0)×2,540(100.0) |
3,515 (7,750) |
4 FLG |
EH4000 |
113.3 (4,000) |
36 |
2,134(84.0)×2,591(102.0)×2,337(92.0) |
4,965 (10,950) |
6 FLG |
EH5000 |
141.6 (5,000) |
50 |
2,311(91.0)×3,048(120.0)×2,464(97.0) |
6,009 (13,248) |
6 FLG |
H6000 |
169.9 (6,000) |
60 |
2,413(95.0)×3,353(132.0)×2,616(103.0) |
7,120 (15,696) |
6 FLG |
EH8000 |
226.5 (8,000) |
75 |
2,565(101.0)×3,962(156.0)×2,667(105.0) |
8,122 (17,910) |
8 FLG |
