型號名稱 |
容量@ 580 PSIG M3/ MIN(SCFM) |
容量@ 450 PSIG M3/ MIN(CFM) |
長X寬X高MM(IN) |
重量KG(LB) |
連接空氣進/出 |
D890NC-HP |
15 (525) |
14 (510) |
826(32.5)×711(28)×1473(58) |
279 (615) |
1 1/2"MPT |
D1090NC-HP |
18 (640) |
18 (625) |
826(32.5)×711(28)×1473(58) |
333 (735) |
2"MPT |
D1340NC-HP |
22 (790) |
22 (770) |
826(32.5)×711(28)×1473(58) |
340 (750) |
2"MPT |
D2040NC-HP |
34 (1,200) |
33 (1,175) |
1,016(40.0)×1,041(41)×1,575(62) |
499 (1,100) |
3"MPT |
D2770NC-HP |
46 (1,630) |
45 (1,600) |
1,016(40.0)×1,041(41)×1,575(62) |
642 (1,415) |
3"MPT |
D4290NC-HP |
71 (2,525) |
70 (2,470) |
1,930(76.0)×838(33)×1,753(69) |
1,254 (2,765) |
4"FLG |
D5635NC-HP |
94 (3,315) |
91 (3,230) |
2,311(91.0)×838(33)×1,905(75) |
1,780 (3,925) |
6"FLG |
D7065NC-HP |
118 (4,150) |
113 (4,000) |
2,311(91.0)×838(33)×1,905(75) |
1,889 (4,165) |
6"FLG |
D8585NC-HP |
143 (5,060) |
140 (4,940) |
2,438(96.0)×1,930(76)×2,540(100) |
2,461 (5,425) |
8"FLG |
D11280NC-HP |
188 (6,635) |
183 (6,460) |
2,438(96.0)×1,930(76)×2,540(100) |
3,232 (7,125) |
8"FLG |
