型號名稱 |
頻率(HZ) |
額定功率KW(HP) |
能力M3 / MIN(CFM) |
排氣壓力BAR G(PSIG) |
長X寬X高MM(IN) |
重量KG(LB) |
UP6 40 115 |
60 |
30 (40) |
5.3 (188) |
8.0 (115) |
1,712(67.4)x1,379(54.3)x1,344(52.9) |
1,105 (2,436) |
UP6 40 125 |
60 |
30 (40) |
5.2 (185) |
8.5 (125) |
1,712(67.4)x1,379(54.3)x1,344(52.9) |
1,105 (2,436) |
UP6 40 150 |
60 |
30 (40) |
4.8 (170) |
10.0 (150) |
1,712(67.4)x1,379(54.3)x1,344(52.9) |
1,105 (2,436) |
UP6 40 200 |
60 |
30 (40) |
4.0 (143) |
14.0 (200) |
1,712(67.4)x1,379(54.3)x1,344(52.9) |
1,105 (2,436) |
UP6 50PE 115 |
60 |
37 (50) |
6.0 (212) |
8.0 (115) |
1,712(67.4)x1,379(54.3)x1,344(52.9) |
1,123 (2,476) |
UP6 50PE 125 |
60 |
37 (50) |
5.9 (208) |
8.5 (125) |
1,712(67.4)x1,379(54.3)x1,344(52.9) |
1,123 (2,476) |
UP6 50PE 150 |
60 |
37 (50) |
5.7 (201) |
10.0 (150) |
1,712(67.4)x1,379(54.3)x1,344(52.9) |
1,123 (2,476) |
UP6 50PE 200 |
60 |
37 (50) |
4.7 (167) |
14.0 (200) |
1,712(67.4)x1,379(54.3)x1,344(52.9) |
1,123 (2,476) |
UP5 30 7 |
50 |
30 (40) |
5.4 (191) |
7.5 (110) |
1,712(67.4)x1,379(54.3)x1,344(52.9) |
1,028 (2,266) |
UP5 30 8 |
50 |
30 (40) |
5.1 (180) |
8.5 (125) |
1,712(67.4)x1,379(54.3)x1,344(52.9) |
1,028 (2,266) |
UP5 30 10 |
50 |
30 (40) |
4.8 (169) |
10.0 (145) |
1,712(67.4)x1,379(54.3)x1,344(52.9) |
1,028 (2,266) |
UP5 30 14 |
50 |
30 (40) |
3.9 (138) |
14.0 (200) |
1,712(67.4)x1,379(54.3)x1,344(52.9) |
1,028 (2,266) |
UP5 37PE 7 |
50 |
37 (50) |
6.0 (212) |
7.5 (110) |
1,712(67.4)x1,379(54.3)x1,344(52.9) |
1,064 (2,346) |
UP5 37PE 8 |
50 |
37 (50) |
5.9 (208) |
8.5 (125) |
1,712(67.4)x1,379(54.3)x1,344(52.9) |
1,064 (2,346) |
UP5 37PE 10 |
50 |
37 (50) |
5.7 (201) |
10.0 (145) |
1,712(67.4)x1,379(54.3)x1,344(52.9) |
1,064 (2,346) |
UP5 37PE 14 |
50 |
37 (50) |
4.7 (167) |
14.0 (200) |
1,712(67.4)x1,379(54.3)x1,344(52.9) |
1,064 (2,346) |
