UP6系列 30-37kW IR微油空氣壓縮機(配備整合式空氣系統)

UP6系列 30-37kW IR微油空氣壓縮機(配備整合式空氣系統) Inquiry

NEXT PREV BACK TO LIST

UP6 Series泛油旋轉螺杆式壓縮機提供卓越的價值，同時不會犧牲您對英格索蘭的可靠性，以易於使用、易於存取的緊湊設計提供高效的性能，藉此提供完整的空氣解決方案。而納入選用的整體空氣系統(TAS)，可讓您在符合成本效益的單一套件中，獲得乾淨、乾燥的空氣。

型號名稱	頻率(HZ)	額定功率KW(HP)	能力M3 / MIN(CFM)	排氣壓力BAR G(PSIG)	長X寬X高MM(IN)	重量KG(LB)
UP6 40 115	60	30 (40)	5.3 (188)	8.0 (115)	1,712(67.4)x1,379(54.3)x1,344(52.9)	1,105 (2,436)
UP6 40 125	60	30 (40)	5.2 (185)	8.5 (125)	1,712(67.4)x1,379(54.3)x1,344(52.9)	1,105 (2,436)
UP6 40 150	60	30 (40)	4.8 (170)	10.0 (150)	1,712(67.4)x1,379(54.3)x1,344(52.9)	1,105 (2,436)
UP6 40 200	60	30 (40)	4.0 (143)	14.0 (200)	1,712(67.4)x1,379(54.3)x1,344(52.9)	1,105 (2,436)
UP6 50PE 115	60	37 (50)	6.0 (212)	8.0 (115)	1,712(67.4)x1,379(54.3)x1,344(52.9)	1,123 (2,476)
UP6 50PE 125	60	37 (50)	5.9 (208)	8.5 (125)	1,712(67.4)x1,379(54.3)x1,344(52.9)	1,123 (2,476)
UP6 50PE 150	60	37 (50)	5.7 (201)	10.0 (150)	1,712(67.4)x1,379(54.3)x1,344(52.9)	1,123 (2,476)
UP6 50PE 200	60	37 (50)	4.7 (167)	14.0 (200)	1,712(67.4)x1,379(54.3)x1,344(52.9)	1,123 (2,476)
UP5 30 7	50	30 (40)	5.4 (191)	7.5 (110)	1,712(67.4)x1,379(54.3)x1,344(52.9)	1,028 (2,266)
UP5 30 8	50	30 (40)	5.1 (180)	8.5 (125)	1,712(67.4)x1,379(54.3)x1,344(52.9)	1,028 (2,266)
UP5 30 10	50	30 (40)	4.8 (169)	10.0 (145)	1,712(67.4)x1,379(54.3)x1,344(52.9)	1,028 (2,266)
UP5 30 14	50	30 (40)	3.9 (138)	14.0 (200)	1,712(67.4)x1,379(54.3)x1,344(52.9)	1,028 (2,266)
UP5 37PE 7	50	37 (50)	6.0 (212)	7.5 (110)	1,712(67.4)x1,379(54.3)x1,344(52.9)	1,064 (2,346)
UP5 37PE 8	50	37 (50)	5.9 (208)	8.5 (125)	1,712(67.4)x1,379(54.3)x1,344(52.9)	1,064 (2,346)
UP5 37PE 10	50	37 (50)	5.7 (201)	10.0 (145)	1,712(67.4)x1,379(54.3)x1,344(52.9)	1,064 (2,346)
UP5 37PE 14	50	37 (50)	4.7 (167)	14.0 (200)	1,712(67.4)x1,379(54.3)x1,344(52.9)	1,064 (2,346)
